PU Edge-Sealed Fireproof Rock Wool (Glass Wool) Sandwich Panels adopt two layers of high-quality color-coated steel sheets or other precision profiled metal sheets as face panels.
After roll forming, cut glass wool strips are flipped 90 degrees to align their fibers perpendicular to the upper and lower steel plates. Premium glass wool core is firmly bonded to metal facings via high-strength, high-adhesion and fire-resistant adhesives, forming aesthetic, flat, rigid and tough building panels.
The finished panels deliver outstanding fire resistance, thermal insulation and environmental performance, making them an ideal solution for industrial building enclosure systems.
Equipped with fireproof polyurethane edge sealing technology, the panels boost airtightness and watertightness at lap/insert joints, effectively eliminate thermal bridging, and prevent delamination between joint sections and core material during transportation and installation.
Advantages
High rigidity, good drainage performance, strong negative wind pressure resistance, tight lap joint, fast construction speed.
System Composition
Top profiled steel plate + High quality rock wool / glass wool core + Bottom profiled steel plate + Polyurethane side seal.
Product Features
1. Fireproof glass wool roof panel adopts lap joint design, making the splicing tight.
2. Unique waterproof groove design effectively prevents rainwater leakage and avoids thermal bridge effect.
3. 36mm wave peak height greatly improves the bearing capacity of roof panel.
4. While ensuring thermal insulation effect, it reduces project cost; the minimum roof slope can be 3%.
Roof
Wall
Roofing System Parameters
| Item | Details |
|---|---|
| Effective Width | 1000mm |
| Panel Thickness | 50mm, 75mm, 100mm, 150mm, 200mm (customizable) |
| Total Length | Customized according to design, transportation and installation requirements |
| Corrugation Dimension | Corrugation height: 36mm; Pitch between peaks: 500mm |
| Inner & Outer Face Sheet Thickness | 0.4~0.8mm |
| Optional Face Materials | Color-coated steel sheet, galvanized steel sheet, anti-static color-coated steel sheet |
| Panel Composition | Top profiled steel sheet + rock wool/glass wool core + bottom profiled steel sheet + PU edge sealing on both sides |
| Connection Type | Lap joint, fixed by self-drilling screws at joints |
| Core Advantages | High rigidity, excellent drainage, strong negative wind pressure resistance, tight lap sealing, fast construction |
| Product Features | 1. Tight lap joints; 2. Special waterproof groove prevents rainwater leakage and eliminates thermal bridging; 3. 36mm high corrugation greatly improves roof load capacity; 4. Stable thermal insulation, reduces construction cost; minimum roof slope reaches 3% |
General Wall System Parameters
| Item | Details |
|---|---|
| Effective Width | 400~1200mm |
| Panel Thickness | 50mm, 75mm, 100mm, 150mm, 200mm (customizable) |
| Total Length | Customized according to design, transportation and installation requirements |
| Inner & Outer Face Sheet Thickness | 0.4~0.8mm |
| Optional Face Materials | Color-coated steel sheet, aluminum-magnesium-manganese alloy sheet |
| Panel Composition | Top profiled steel sheet + rock wool/glass wool core + bottom profiled steel sheet + PU edge sealing on both sides |
| Connection Method | Fixed to purlins with self-drilling screws, interlocking joint connection |
| Application Scope | Non-load-bearing wall enclosures for steel structures including industrial workshops, civil buildings and public buildings |
FAQ
1. What are the main problems with traditional steel structure panels?
Traditional glass wool or rock wool panels often cause construction troubles:
Leakage & Air infiltration at joints.
Thermal bridging leading to condensation.
Core delamination during transport.
Weak wind resistance and unstable fire performance.
These issues lead to rework costs and a short service life. Our Solution: Our PU edge-sealed panel solves these with full polyurethane sealing and a vertical fiber core for long-term building safety.
2. What makes your panel different from ordinary ones?
Most standard panels have exposed fiber edges that easily absorb water and deform.
Our core advantage is the full polyurethane edge sealing. With no exposed core fiber, the sealed edge perfectly matches steel structure laps, greatly improving airtightness, watertightness, and preventing core delamination.
3. Can this panel ensure fire safety and insulation?
Yes. We use a 90-degree vertical fiber flipping process. Unlike horizontal cotton, this vertical structure provides more stable fire resistance and reduces heat loss. It effectively prevents indoor condensation, keeping your factory at a stable temperature.
4. What applications is this panel suitable for?
It is a special supporting material for steel structure enclosure systems, widely used for non-load-bearing walls and roofs of:
Steel structure factory workshops.
Industrial warehouses.
Large-span steel structure plants.
We provide two complete systems: Roof Panel and Wall Panel systems, with customizable thickness and length.
5. Do you have different wall profiles for decoration?
Yes. We supply two popular profiles:
Water Wave Profile: Soft 3D texture for an elegant visual effect.
Square Rib Profile: Neat concave-convex lines for a modern, industrial appearance.
6. Can this panel speed up construction?
Absolutely. All panels are fully prefabricated in the factory. On-site secondary cotton filling and glue sealing are not required. This standardized interlocking structure saves significant construction time and labor costs.
7. How to avoid panel delamination and short service life?
Steel buildings are affected by wind vibration and temperature changes. Our panels use high-adhesion structural adhesive and PU edge sealing to protect the core from moisture and damage, greatly improving overall durability and service life.
8. What custom specifications can you provide?
Roof Panel: Effective width 1000mm; Thickness 50-200mm; 36mm high wave for strong load capacity.
Wall Panel: Effective width 400–1200mm; Color-coated steel or Al-Mg-Mn sheet available.
